CNC Chucker
The JV-45 linear tooling is a Chucker and cnc lathe. ideally suited for job shops and ancillaries to produce automobile and electronic components, bearing races and more in medium and large batches. The elements like ball screws, bearings, LM guides, spindle motor, state of the art CNC system, drives and couplings have been chosen from world renowned manufactureres.
- Customized tooling.
- A2-5 spindle supported by angular contact bearings for high speed and rigidity
- Continues lubrication for ball screw and LM guides
- User friendly state of art CNC system Siemens808
- Hydraulic power pack.
-
- Automatic centeralized lubrication system.
- Built in lighting system.
- Face and ID tool holders.
- Machine occupies lesser floor area.
note :-    Specifications may change due to continuous improvement in design.
